Click to enlarge image
We recommend checking out our discussion threads on the APC Power-Saving Back-UPS Pro 1200 International BR1200GI,
which address similar problems with connecting and setting up UPS Backup APC.
User manual for the APC Power-Saving Back-UPS Pro 1200 International BR1200GI
The user manual for the APC Power-Saving Back-UPS Pro 1200 International BR1200GI provides
necessary instructions for the proper use of the product Computers & Solutions - Power - UPS Backup.
The Power-Saving Back-UPS Pro 1200 International Version (230V) from APC provides power to your important computer components in the event of an electrical outage. The Uninterruptible Power Supply (UPS) contains a battery which continues to power computers, monitors and other components if the electricity is cut from them. An LCD status display provides information including remaining battery life, load capacity, and event notices. The battery is hot-swappable and easy to replace. An audible alarm alerts you of events like power outage and low battery.
If you own a APC ups backup and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the APC Power-Saving Back-UPS Pro 1200 International BR1200GI in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the APC Power-Saving Back-UPS Pro 1200 International BR1200GI:
Specifications
Output
Output Power Capacity: 720 W/1200 VA Nominal Output Voltage: 230V Efficiency at Full Load: 89.0% Output Frequency (sync to mains): 50 Hz,60 Hz Crest Factor: 3 : 1 Topology: Line Interactive Waveform Type: Stepped approximation to a sinewave Output Connections: • 5x IEC 320 C13 / Battery Backup • 5x IEC 320 C13 / Surge Protection • 2x IEC Jumpers / Battery Backup Efficiency at Half Load: 85%
Input
Nominal Input Voltage: 230V Input Frequency: 50/60 Hz +/- 3 Hz (auto sensing) Input Connections: IEC-320 C14 Input voltage range for main operations: 176 - 294V Input voltage adjustable range for mains operation: 156 - 300V Input Breaker Capacity: 10.0 A
Batteries & Runtime
Battery Type: Maintenance-free sealed Lead-Acid battery with suspended electrolyte, leakproof Typical recharge time: 8 hours Replacement Battery: APCRBC124 RBC Quantity: 1 Full load: 8 min / 720W Half Load: 20 min / 360W
Communications & Management
Interface Port: USB Control panel: Multi-function LCD status and control console Audible Alarm: Alarm when on battery, distinctive low battery alarm, overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating: 441 Joules Filtering: Full time multi-pole noise filtering, 10% of IEEE surge let-through, zero clamping response time instantaneous Data Line Protection: Analog phone line for phone/fax/modem/DSL (RJ-11 connector),Network line - 10/100/1000 Base-T Ethernet (RJ-45 connector)
Conformance
Regulatory Approvals A-tick,C-tick,CE,GOST,GS Mark,Telepermit,TUV Environmental Compliance: RoHS,REACH. Contains No SVHCs
Environmental Requirements
Operating Temperature: 32 - 104°F / 0 to 40°C Storage Temperature: 23 - 113°F / -15 to 45°C Humidity: 0-95% Operating Elevation: 10,000' / 3000 m Storage Elevation: 50,000' / 15,000 m
