User manual for the Humminbird 698ci HD SI Combo Fishfinder 409470-1
The user manual for the Humminbird 698ci HD SI Combo Fishfinder 409470-1 provides
necessary instructions for the proper use of the product Optics - Outdoor Gear - Fishing & Marine Technology.
Track down your next elusive catch with the Humminbird 698ci HD SI Combo Fishfinder, featuring DualBeam PLUS Sonar with SwitchFire for versatile coverage and depth as well as Down Imaging Sonar for a more precise view of what's below you with high-frequency sound waves and Side Imaging Sonar that provides a 180° view of objects to the side of your boat. Down Imaging technology scans the water with a beam that is wide side to side by thin front to back in order to produce high definition images while Side Imaging uses multiple beams to cover a wide area for detailed bottom topography and fish-attracting structures.
These systems are rated to work at depths up to 100' (DI/SI) & 1500' (2D) and has a peak to peak power output of 4000W. Also, they can be setup with multiple coverage angles of 20, 60, and 2x 85° for a total of 180° due to the use of the DualBeam PLUS sonar system and the SwitchFire enables users to setup multiple views simultaneously. Viewing imagery while out in the elements is no issue with the implementation of a 5" LED-backlit color TFT LCD with a resolution of 480 x 640 pixels. Additionally, this unit has a built-in GPS system with chartplotting capabilities and the UniMap cartography system.
The 698ci has an SD card slot for advanced cartography, saving screenshots, sonar recordings, and waypoints as well as updating the internal software. For protection in all elements and just the nature of being near water, this device is IP67-rated from waterproofing down to 3.3' for 30 minutes. And, it has a tilt and swivel quick disconnect mount.
If you own a Humminbird fishing & marine technology and have a user manual in electronic form,
you can upload it to this website using the link on the right side of the screen.
You can upload and download the manual for the Humminbird 698ci HD SI Combo Fishfinder 409470-1 in the following formats:
*.pdf, *.doc, *.txt, *.jpg - Other formats are unfortunately not supported.
Additional parameters of the Humminbird 698ci HD SI Combo Fishfinder 409470-1:
IP67 waterproof/submersible to 3.3' (1 m) for 30 minutes and dust tight
LCD Screen
5" (12.7 cm) 480 x 640 LED-backlit color TFT LCD
Grayscale
256 levels
Power Requirements
10-20 VDC
Power Consumption
615 mA
Dimensions
6.9 x 7.5 x 4.5" (17.5 x 19.1 x 11.4 cm) with gimbal mount 6.9 x 5.4 x 1.3" (17.5 x 13.7 x 3.2 cm) with optional in-dash mount
The user manual for the Humminbird 698ci HD SI Combo Fishfinder 409470-1 can be downloaded in .pdf
format if it did not come with your new fishing & marine technology, although the seller is
required to supply one. It is also quite common that customers throw out
the user manual with the box, or put the CD away somewhere and then can’t find it.
That’s why we and other Humminbird users keep a unique electronic library
for Humminbird fishing & marine technologys,
where you can use our link to download the user manual for the Humminbird 698ci HD SI Combo Fishfinder 409470-1.
The user manual lists all of the functions of the Humminbird 698ci HD SI Combo Fishfinder 409470-1,
all the basic and advanced features and tells you how to use the fishing & marine technology.
The manual also provides troubleshooting for common problems. Even greater
detail is provided by the service manual, which is not typically shipped with the product,
but which can often be downloaded from Humminbird service.
If you want to help expand our database, you can upload a link to this website
to download a user manual or service manual, ideally in .pdf format. These pages
are created by you – users of the Humminbird 698ci HD SI Combo Fishfinder 409470-1. User manuals are also
available on the Humminbird website under Optics - Outdoor Gear - Fishing & Marine Technology.
